XRUS-G10
Resonant ultrasound spectrometer with the function of characterizing piezoelectric crystals
XRUS-G10 Features
Easy to operate
✓ Characterization of all elastic and piezoelectric constants of piezoelectric crystals with a single sample
✓ Feature-rich software with user-friendly interface and pre-set material parameters for a wide range of materials
Revolutionary innovation
✓ Resonant ultrasound spectrometer with the function of characterizing piezoelectric crystals
Characterization of multiple sample types
✓ Characterization of all elastic constants of alloys, rocks, and other solids with a single sample
✓ Non-destructive testing of cracks in solid parts (ASTM International Standard E2001-18)
High and low temperature tests
✓ In combination with our high-temperature ultrasonic transducers, the temperature dependence of the elastic and piezoelectric constants of piezoelectric crystals can be characterized
✓ Characterization of the temperature dependence of the elastic constants of alloys and ceramics
XRUS-G10 Parameters
✓ Bandwidth: 50 kHz–3 MHz
✓ Maximum Output: 90 Vp–p @ 1 MHz
✓ Piezoelectric crystals which can be characterized*: 32, 422, 3m, 4mm, 6mm, mm2 (others can be customized)
✓ Solid samples without piezoelectricity which can be characterized: Customizable for all types
✓ Temperature range: RT, -20°C–40°C; AT, -20°C–200°C (equipped with high-temperature transducers, fixtures and environmental chamber)
✓ Operating System: Windows 7 x64 and higher, Ubuntu x64 22.04
Note:
- 32: LGS, LGT, etc.
- 422: α-FeO2, etc.
- 3m: LiNbO3, [111]c poled relaxor based single crystals, etc.
- 4mm: [001]c poled relaxor based single crystals, etc.
- 6mm: BaTiO3, Bi4Ti3O12, PZT, etc.
- mm2: [011]c poled relaxor based single crystals, etc.
Application Case I Application Case II Application Case III Application Case IV
Characterization of [111]c poled PIN-PMN-PT single crystals
A. L. Xiao, L. G. Tang*, G. S. Xu*, K. C. Wu, W. Y. Luo, Temperature-dependent characterization of full tensor properties of [111]c poled Mn-doped 28PIN-43PMN-29PT single crystals, Applied Physics Letters, 124, 212901, 2024.
Application Case I Application Case II Application Case III Application Case IV
Characterization of [001]c poled PIN-PMN-PT single crystals
L. G. Tang*, H. Tian, Y. Zhang, and W. W. Cao*, Temperature dependence of dielectric, elastic, and piezoelectric constants of [001]c poled Mn-doped 0.24Pb(In1/2Nb1/2)O3-0.46Pb(Mg1/3Nb2/3)O3-0.30PbTiO3 single crystal, Applied Physics Letters, 108(8): 082901, 2016.
Application Case I Application Case II Application Case III Application Case IV
Non-destructive testing for lithium batteries
Patent: A device and method for detecting lithium battery based on resonant ultrasound spectroscopy, Liguo Tang, Shujia Wang, Shaofei Wang, Jiahe Zang
Application Case I Application Case II Application Case III Application Case IV
Characterization of material constants of LGT crystals under high-temperature
High-temperature Resonant Ultrasound Spectroscopy system
Resonance ultrasonic spectra of LGT crystal samples at 20°C and 400°C
| Elastic and piezoelectric constants of LGT single crystals Characterized Using RUS |
| Temperature (°C) |
Elastic Constants cE ij (1010 N/m2) |
Piezoelectric Constants eij (C/m2) |
|||||||
| cE 11 | cE 12 | cE 13 | cE 14 | cE 33 | cE 44 | e11 | e14 | ||
| 20 | 18.586 | 10.524 | 9.785 | 1.353 | 26.003 | 5.093 | -0.439 | 0.123 | |
| 400 | 18.346 | 10.314 | 9.694 | 1.256 | 25.340 | 5.056 | -0.429 | 0.209 |
